Dahua IPC-HFW1530S-0360B-S6 5MP IP security camera

Related products

• Details
• Data
• Reviews

Details

Dahua IPC-HFW1530S-0360B-S6 IP security camera with 5MP 2K resolution, motion detection, 30 m night vision range and durable metal housing

The Dahua IPC-HFW1530S-0360B-S6 is a 5 megapixel IP camera with motion detection that can automatically detect motion events, start recording immediately and send alerts to the user. For optimal night surveillance, it is equipped with a high‑performance IR LED that provides clear images up to 30 meters even in complete darkness. The camera features DWDR, which improves image quality in challenging lighting conditions (for example, when facing direct sunlight, the camera compensates to deliver a usable image). Designed for outdoor use, it comes in a robust metal housing with IP67 weatherproof rating, protecting it against rain, dust and sunlight. It supports H.265+ compression, which is especially important for IP cameras as it reduces required bandwidth and storage space for recordings. Easy installation is ensured by PoE, as both video signal and power are transmitted over a single UTP cable, eliminating the need for multiple cables. The camera is equipped with a built‑in microphone.

5

MEGAPIXEL

Dahua IP camera

3.6mm

FIXED LENS

Approx. 92° field of view

30m

NIGHT VISION RANGE

Maximum range in complete darkness

IP67

RATING

Weather‑resistant design

Detailed technical specifications

CAMERA TYPE	IP camera
DESIGN	Compact, Bullet
VIDEO STANDARDS	IP
KEY FEATURES	Built‑in microphone
VIDEO ANALYTICS	Line crossing, Area intrusion
MEGAPIXELS	5 MP
INSTALLATION LOCATION	Outdoor
COLOR	White
HOUSING MATERIAL	Metal
CAMERA FUNCTIONS	DWDR, HLC, BLC, Corridor mode, ROI, Privacy mask, P2P
MAX RESOLUTION @ FPS	2688 (H) × 1520 (V) @ 20fps
INGRESS PROTECTION	IP67
SUPPORTED RESOLUTIONS	2688 × 1520 (2688 × 1520); 2560 × 1440 (2560 × 1440); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576 / 704 × 480); VGA (640 × 480); CIF (352 × 288 / 352 × 240)
IMAGE SENSOR	1/2.7" CMOS
SENSITIVITY	0.003 Lux
LENS TYPE	Fixed
FOCAL LENGTH	3.6 mm
FIELD OF VIEW	92°
FOCUS MODE	Fixed focus

IRIS	Fixed
ILLUMINATOR	IR LED
IR RANGE	30 m
ELECTRONIC SHUTTER SPEED	1/3 – 1/100000
SHUTTER MODE	Auto, Adjustable
COMPRESSION	Smart H.265+; Smart H.264+
ROI	Yes
CORRIDOR MODE	Yes
MULTICAST	Yes
NOISE REDUCTION	3D DNR
WIDE DYNAMIC RANGE	DWDR
WDR	DWDR
BACKLIGHT COMPENSATION	HLC, BLC
MOTION DETECTION	Yes
PRIVACY MASKING	Yes
ALARM EVENTS	Motion, Video analytics, Tampering, Illegal login, IP conflict, Network loss, System error, Audio change, Storage error
CONFIGURATION INTERFACE	Web
AUDIO	Built‑in microphone
CONNECTORS	DC-in, LAN, PoE
POWER SUPPLY	12V DC / PoE (802.3af)
MAX POWER CONSUMPTION	5W (PoE)
OPERATING TEMPERATURE	-40 °C to +60 °C
DIMENSIONS	162.6 mm × 70 mm × 70 mm
WEIGHT	320 g

Data

Kameradesign:

Cső

Area of ​​use:

Kültér és beltér

Functions:

, , ,
