Amiko XVR420 4-channel 8MP Lite XVR recorder

Name: Amiko XVR420 4-channel 8MP Lite XVR recorder
Brand: Amiko
SKU: XVR420
Price: 76.63 EUR
Availability: InStock

In stock 2 pcs

RRP: 111.26 €

76.63 €

Savings 34.63 €

Beszerelt-ellenőrzött HDD

4,8 / 5 4 736 vásárlói értékelés

Garancia24 hónap

Szállítás1–2 munkanap

Műszaki segítségorkodo@orkodo.comMunkaidőben: 06 20 379 2733

Details

Amiko XVR420 4-channel 8MP XVR recorder with Hungarian menu and mobile access

The Amiko XVR420 is an excellent central solution for CCTV systems, featuring an easy-to-use Hungarian menu. It uses the latest H.265+ compression technology, enabling fast and efficient recording of high-resolution video while reducing storage requirements. The device supports ONVIF, ensuring wide compatibility with other IP cameras and recorders. With support for 8MP, 4 analog or 16 IP (5MP) camera modes, the XVR420 delivers high-quality recording. The XVR recorder is compatible with Analog, AHD, CVI, TVI 2.0, TVI 3.0 standards and IP cameras, making the system easy to customize and expand. The XVR420 allows real-time live viewing on Android and iOS devices, so you can check your property from anywhere. The video recorder includes 1 SATA HDD/SSD slot supporting up to 8TB (not included), providing ample capacity for long-term video archiving.

8

MEGAPIXELS

Maximum resolution

8 TB

MAX STORAGE

Maximum storage capacity

4

CHANNELS

Connect up to 4 cameras

H.265+

VIDEO COMPRESSION

Up to 75% more efficient than older systems

Detailed technical specifications

Video:
Input:	Analog: 4 × (1920 × 2160 4 × 8fps)
Analog + Network:	2 × Analog + 7 × Network (Max 5MP)
IP:	16 × 5MP/4MP/3MP/1080P/960P/720P (Total incoming bandwidth ≤ 48M)
Input:	4CH BNC
Signal type:	Analog/AHD/CVI/TVI 2.0/IP
Output:	1 × HDMI, 1 × VGA
Audio:
Input:	2 channels, RCA
Output:	1 channel, RCA
Hard disk drive:
Interface type:	1 × SATA interface
Capacity:	1 × SATA hard disk (2.5"/3.5" SATA, up to 8TB)
Physical specifications:
USB interface:	2 × USB 2.0 ports
Power consumption:	DC 12V ≤ 6W (without hard disk)
Operating environment:	-10~55℃ / 10~90% RH
Dimensions (W × D × H):	260 × 215 × 43 mm
Weight:	2kg (without hard disk)

Display:
VGA:	Resolution: 1920 × 1080P/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
HDMI output:	Resolution: 1920 × 1080P/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Display split:	9-channel/4-channel/1-channel view
Privacy masking:	3 rectangular zones (per camera)
OSD:	Camera title, Time, Video loss, Alarm, Motion detection, Recording
Network:
Interface:	1 × RJ45 10M/100M adaptive Ethernet port
Network functions:	TCP/IP, HTTP, UPnP, DNS, NTP, SMTP, PPPoE, DHCP, FTP, DDNS, RTP, RTSP, RTCP
DDNS:	Dyndns, No-ip, Oray
Web browser:	IE8-11, Google Chrome (below Ver44), Firefox (below Ver53)
CMS software:	Supports Windows 7/Windows 8/Windows 10
Sub stream:	CIF (1~25fps)
Smartphone:	iPhone, iPad, Android, Android pad
